BKM Servo Gear Reducer Model Selection

The following is the model selection reference of the BKM series servo gear reducer:

(n1=1500r/min)
BKM ST 7.5 10 12.5 15 20 25 30 40 50 60 75 100 125 150 200 250 300
050 100W √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √
200W ● ● ● √ √ √ √ √ √ √ √ √
400W √ √ √ √ √ √ √ √ √
500W √ √ √ √ √ √ √ √
750W √ √ √ √ √ √ √
1000W √ √ √
1500W √ √ √
063 200W ● ● ● ● ● ● ● √ √ √ √ √ √ √
400W ● ● ● √ √ √ √ √ √ √
500W √ √ √ √ √ √ √ √ √ √
750W √ √ √ √ √ √ √ √ √
1000W √ √ √ √ √ √ √ √ √ √
1500W √ √ √ √ √ √
075 400W ● ● ● ● ● ● ● √ √ √ √ √ √
500W ● ● ● √ √ √ √ √ √ √ √
750W ● ● ● √ √ √ √ √ √ √
1000W √ √ √ √ √ √ √ √ √ √
1500W √ √ √ √ √ √ √ √ √
2000W √ √ √ √ √ √ √
3000W √ √ √
4000W √ √ √
090 400W ● ● ● ● ● ● ● √ √ √ √ √ √ √ √
500W ● ● ● ● ● ● √ √ √ √ √ √ √ √
750W ● ● ● √ √ √ √ √ √ √ √ √ √
1000W ● ● ● √ √ √ √ √ √ √ √
1500W √ √ √ √ √ √ √ √ √ √
2000W √ √ √ √ √ √ √ √
3000W √ √ √ √ √ √ √
4000W √ √ √
110 750W ● ● ● ● ● ● ● √ √ √ √ √ √ √ √
1000W ● ● ● ● √ √ √ √ √ √ √ √ √
1500W ● ● ● √ √ √ √ √ √ √
2000W √ √ √ √ √ √ √ √ √ √
3000W √ √ √ √ √ √ √ √
4000W √ √ √ √ √ √ √
5000W √ √ √ √ √

● means that the configuration is available but not recommended;
The blank means that the configuration is not available;
√ means that the combination of electric motor and speed reducer is available.
